FERROUS POWDER METALLURGY SINTERING TROUBLESHOOTING GUIDE

Download the Ferrous PM Sinterng Troubleshooting Guide

Safety Warning for Hydrogen Atmosphere Furnace Operation
Operating a hydrogen atmosphere furnace involves significant risks. Adherence to safety guidelines is essential to ensure safe operation:
General Safety Guidelines
1. Flammable Environment: Hydrogen is highly flammable. Ensure that all ignition sources are eliminated in the vicinity of the furnace.
2. Ventilation: Maintain adequate ventilation in the area to prevent the accumulation of hydrogen gas, which can be explosive at concentrations
as low as 4% in air.
3. Personal Protective Equipment (PPE):
• Wear appropriate PPE, including flame-resistant clothing, gloves, and safety goggles.
• Use respiratory protection if there is a risk of inhaling harmful gases.
4. Leak Detection:
• Implement hydrogen leak detection systems. Regularly check for leaks using appropriate detection equipment.
• In case of a hydrogen leak, evacuate the area immediately and notify emergency personnel.
5. Safe Handling and Storage:
• Store hydrogen cylinders in a secure, upright position, away from heat sources and flammable materials.
• Ensure that all connections and fittings are secure and leak-free.
6. Emergency Procedures:
• Familiarize yourself with emergency shutdown procedures for the furnace.
• Know the location of emergency exits and fire extinguishers.
7. Training: Ensure that all personnel operating the furnace are properly trained in hydrogen safety and emergency response.
8. Regular Maintenance: Conduct routine inspections and maintenance of the furnace and associated equipment to ensure safe operation.
9. In Case of Emergency
• Evacuate the area immediately.
• Activate the emergency shutdown procedures.
• Contact emergency services and provide them with information about the hydrogen atmosphere furnace.
10. Failure to adhere to these safety guidelines can result in serious injury or death. Always prioritize safety and remain vigilant.


SEARCH

Furnace Belt Issue

Part Issue for Ferrous PM Materials

TYPICAL POWDER METALLURGY SINTERING FURNACE TESTING PROCEDURES

Copper Infiltration Test
By following these steps, you can assess the sintering furnace condition and identify any problems that may need to be addressed. The test is performed as follows:

1. Place a piece of copper infiltrant on a ferrous green part and another piece of copper infiltrant on a ferrous sintered part.
2. Place both assemblies on a ceramic plate and send through the sintering furnace.

Copper/Steel/Stainless Steel Test
To determine if oxidation in the cooling section is caused by an air or water leak, perform the following copper/steel/stainless steel test:
1. Reduce the furnace temperature to 1,900°F
2. Place a piece of bright copper strip, steel strip and stainless-steel strip side by side on the belt and send them through the furnace.
3. Evaluate the 3 materials upon exiting the cooling zones of the furnace:

• Copper will be oxidized by oxygen, but not by water. If the copper is oxidized, there is an air leak in the furnace.
• Steel will be oxidized by both oxygen and water.
• Stainless steel materials are more sensitive to small leaks and will turn green with high dewpoints.

Oxide Formation Insights
Stainless Steel Oxidation:
1. A green oxide film on stainless steel is primarily chromium oxide (CrO), resulting from excess oxygen and/or moisture.
This can be caused by:

• Water leaks.
• Poor atmosphere tightness.
• Low flow rates of atmosphere gas.

2. A dark green-brown color indicates high levels of free oxygen, suggesting significant air leakage.

Advanced Monitoring
Oxygen Analyzer & Dew Point Meter:
     For more accurate diagnostics, install an oxygen analyzer and a dew point meter in the furnace.
     These instruments provide real-time data on oxygen concentration and moisture levels in the furnace atmosphere.

This setup allows operators to make precise measurements and effectively address sintering issues.

Disclaimer: The information provided in these trouble shooting guides is intended for general guidance only. Users are advised to follow manufacturer instructions and safety guidelines when operating their equipment.
Safety First: Always prioritize safety. Ensure that the furnace is properly installed and maintained by qualified personnel with regular inspections and service for safe operation.
Emergency Procedures: Familiarize yourself with emergency shutdown procedures.
Liability: Metal Powder Industries Federation (MPIF) or Center for Powder Metallurgy Technology (CPMT) are not liable for any damages or injuries resulting from improper use, lack of maintenance, or failure to follow the manufacturers and operator
safety procedures.
By using these guides, you acknowledge and accept these terms and conditions. For any questions or concerns, please consult a qualified technician or the furnace manufacturer directly.
